Tact Switch # 12

Alpha Products,Inc. 351 Irving Drive, Oxnard, CA 93030, USA / T:805-981-8666 / F: 805-988-6555

New Products

Connectors

Potentiometers

RF Products

Assemblies

Contact Us

Quote Request

6 x 6 mm surface mount switch

Part number

3SW/TSMW64N

3SW/TSMW64R



Part number

3SW/TSMW65N

3SW/TSMW65R

3SW/TSMW65T

Dim “H”

4.5 [.177]

Dim “H”

3.5 [.138]

Operating force

180gf

260gf

Operating force

180gf

260gf

360gf

Stroke

0.45mm

Stroke

0.45mm

Stem material

Nylon, UL94V-0

Stem material

Silicone rubber

Stem color

Brown

Red

Stem color

Brown

Red

Transparent



Part number

3SW/TSMW67N

3SW/TSMW67R

3SW/TSMW67T



Part number

3SW/TSMW69N

3SW/TSMW69R

3SW/TSMW69T

Dim “H”

5.2 [.205]

Dim “H”

3.8 [.150]

Operating force

180gf

260gf

360gf

Operating force

180gf

260gf

360gf

Stroke

0.45mm

0.6mm

Stroke

0.45mm

0.6mm

Stem material

Silicone rubber

Stem material

Silicone rubber

Stem color

Brown

Red

Transparent

Stem color

Brown

Red

Transparent

6 x 6 mm through hole switch

Part number

3SW/TSHW64N

3SW/TSHW64R



Part number

3SW/TSHW65N

3SW/TSHW65R

3SW/TSHW65T

Dim “H”

4.5 [.177]

Dim “H”

3.5 [.138]

Operating force

180gf

260gf

Operating force

180gf

260gf

360gf

Stroke

0.45mm

Stroke

0.45mm

Stem material

Nylon, UL94V-0

Stem material

Silicone rubber

Stem color

Brown

Red

Stem color

Brown

Red

Transparent



Part number

3SW/TSHW67N

3SW/TSHW67R

3SW/TSHW67T



Part number

3SW/TSHW69N

3SW/TSHW69R

3SW/TSHW69T

Dim “H”

5.2 [.205]

Dim “H”

3.8 [.150]

Operating force

180gf

260gf

360gf

Operating force

180gf

260gf

360gf

Stroke

0.45mm

0.6mm

Stroke

0.45mm

0.6mm

Stem material

Silicone rubber

Stem material

Silicone rubber

Stem color

Brown

Red

Transparent

Stem color

Brown

Red

Transparent

Specification

Rating

50mA @24V DC

Operating Temperature

-25°C to +70°C

Contact Resistance

100mOhm max

Life

500,000 min

Insulation Resistance

100MOhm min @500V DC

Cover

Stainless steel

Dielectric Strengh

250V AC/minute

Base

Nylon, UL94V-0, black

Operating Force

See table

Stem

See table

Stroke

See table

Terminal

Brass, silver plated
