Part number: 3SW/DTCTE0

Part number: 3SW/DTCTEP

Specifications

Rating

0.1 ~ 100mA@20mV ~ 5V DC

Operating Temperature

-15°C to +70°C

Contact Resistance

500 mOhm max

Life

100,000 cycles

Insulation Resistance

100MOhm @100V DC

Cover

Nylon, UL94V-0, black

Dielectric Strength

250V AC/minute

Base

Nylon, UL94V-0, black

Operating Force

35gf max

Stem

Nylon, UL94V-0, black

Stroke

1.05mm max

Terminal

PhBz, silver plated
