Specification
|
|
Function
|
SPST
|
Operating Temperature
|
-30°C to +80°C
|
|
Non-switching Rating
|
100 mA @50V DC
|
Body Material
|
UL94V-0 high temp., nylon, black
|
|
Switching Rating
|
10 mA @5V DC
|
Contact Material
|
Copper alloy, gold plated
|
|
Contact Resistance
|
100 mOhm max. initial
|
Actuator Material
|
UL94V-0 high temp., nylon, white
|
|
Insulation Resistance
|
100 MOhm @500V DC
|
Terminals
|
Brass, gold plated
|
|
Dielectric Strength
|
300V AC for 1 minute
|
Life
|
500 operations
|
|
Operating Force
|
800 gf max
|
|
|
|
|
|
|
|
