PCB layout
|
|
Code
|
Switching position
|
|
|
|
|
|
A
|
ON
|
NONE
|
ON
|
|
B
|
ON
|
NONE
|
(ON)
|
|
C
|
ON
|
OFF
|
ON
|
|
D
|
(ON)
|
OFF
|
(ON)
|
|
E
|
ON
|
OFF
|
(ON)
|
|
Term. comm.
|
2-3
|
OPEN
|
2-1
|
|
F
|
ON
|
ON
|
ON
|
|
Term. comm.
|
2-3, 5-6
|
2-3, 5-4
|
2-1, 5-4
|
|
|
|
|
|
|
|
Specifications
|
|
Function
|
DPDT
|
Operating Temperature
|
-30°C to +85°C
|
|
Rating
|
See plating option
|
Case
|
Nylon, GF, UL94V-0
|
|
Contact Resistance
|
10mOhm initial
|
Actuator
|
Copper alloy, Cr plated
|
|
Insulation Resistance
|
1000MOhm min
|
Contact & Terminal
|
Copper alloy/steel
|
|
Dielectric Strengh
|
1500V RMS
|
Seal
|
Epoxy
|
|
Life
|
10,000 cycles
|
Protection
|
IP67
|
|
|
|
|
|
Actuator options
|
|
Metal
|
Plastic
|
|
|
Code
|
|
Code
|
|
Code
|
Color
|
|
Code
|
Color
|
|
1
|
2
|
3
|
Black
|
6
|
Black
|
|
4
|
White
|
7
|
White
|
|
5
|
Silver
|
8
|
Silver
|
|
|
|
Bushing options
|
Vinyl cap options
|
|
Code “N”
|
Code “E”
|
Cap for code “1” actuator
|
Cap for code “2” actuator
|
|
|
|
|
Code
|
Color
|
|
Code
|
Color
|
|
A0
|
transparent
|
B0
|
transparent
|
|
A1
|
white
|
B1
|
white
|
|
A2
|
black
|
B2
|
black
|
|
A3
|
red
|
B3
|
red
|
|
A4
|
yellow
|
B4
|
yellow
|
|
A5
|
blue
|
B5
|
blue
|
|
A6
|
green
|
B6
|
green
|
|
A7
|
orange
|
B7
|
orange
|
|
|
|
|
|
Termination options
|
|
Solder, code “B”
|
PCB, code “C”
|
Quick connect, code “Q”
|
Wire wrap
|
|
|
|
|
|
|
Code
|
Dim “A”
|
|
W1
|
19.1 [0.750]
|
|
W2
|
10.8 [0.425]
|
|
|
|
|
|
Contact plating options
|
|
Code
|
Contact plating
|
Terminal plating
|
Rating
|
|
Q
|
Silver
|
Silver
|
6A @125V AC or 28V DC; 3A @250V AC
|
|
R
|
Gold over nickel
|
Gold over nickel
|
0.4VA max @20V AC or DC max
|
|
G
|
Gold over silver
|
Gold over silver
|
0.4VA max @20V AC or DC max
6A @125V AC or 28V DC; 3A @250V AC
|
|
|
|
Support bracket options
|
|
|
|
Code
|
Dim “A”
|
|
1
|
11.7 [0.460]
|
|
2
|
16.0 [0.630]
|
|
3
snap-in
|
11.7 [0.460]
|
|
4
snap-in
|
16.0 [0.630]
|
|
|
Code
|
Dim “A”
|
|
5
|
11.7 [0.460]
|
|
6
|
16.0 [0.630]
|
|
7
snap-in
|
11.7 [0.460]
|
|
8
snap-in
|
16.0 [0.630]
|
|
|
|
|
|
